Width x Depth x Height mm |
640 x 755 x 1535mm (inc feet) |
Feet Height |
165mm to 225mm |
Basket size |
500 x 500mm |
Maximum useable height |
440mm |
Door Opening |
460mm |
Cycle times |
70/90/120 Seconds |
Water consumption per cycle |
2.0 Litres |
Wash tank capacity |
22 Litres |
Phase - Options |
Single/3-Phase |
Power – Single Phase Options |
4.7kW(20Amp),6.7kW(30Amp) |
Power – Three Phase |
6.7kW(16Amp) |
Detergent pump |
Peristaltic - Non Timed |
Rinse aid pump |
Peristaltic - Non Timed |
Drain pump |
Yes |
Breaktank |
Yes |
Water supply pressure |
2 to 4 Bar |
Body Construction |
Double skin |
Door/Hood Construction |
Double skin |
Scrap Trays |
Yes |
Internal Rinse Booster Pump |
Yes |
Number Of Cycles |
3 |
Total Maximum Load(as supplied) |
6.7kW(30A) – Single Phase |
